모델 | 부피 흐름 Nm3/h | 입수 압력 MPa | 배기 압력 MPa | 혁명 rpm | 모터 전력 kW | 냉각 물 흐름 m3/h | 크기 (L×W×H) mm | 무게 톤 |
GL150/0/0.5 | 120-154 | 0 | 00.3 ~ 0.5 | 360 | 30~37 | ≤ 25 | 3200 × 2000 × 2550 | 7.5 |
GL150/0/20 | 40~70 | 0-0.08 | 20 | 360 | 30~37 | ≤3.2 | 3200 × 2000 × 2550 | 7 |
GL150/0.3/20 | 80~260 | 0.3-10 | 20 | 360 | 37~75 | ≤6.0 | 3500 × 2300 × 2550 | 7.5 |
GL150/1/25 | 170~250 | 10.0-15 | 25 | 360 | 75 | ≤6.0 | 3500 × 2400 × 1900 | 7.5 |
GZ150/1.3/20 | 40-1100 | 1.3-160 | 20 | 360 | 22~37 | ≤3.2 | 2600 × 1630 × 2550 | 6 |
GZ150/10/80 | 90~500 | 100.0-40.0 | 80 | 360 | 22~37 | ≤3.2 | 2600 × 1630 × 2550 | 6 |
GL165/0.3/20 | 90~300 | 0.3-10 | 20 | 360 | 37~75 | ≤6.0 | 3500 × 2300 × 2550 | 9 |
GL165/0.3/25 | 75~250 | 0.3-12 | 25 | 360 | 37~75 | ≤6.0 | 3500 × 2300 × 2550 | 9 |
GL165/1/25 | 200~300 | 10.0-15 | 25 | 360 | 37~75 | ≤6.0 | 3500 × 2300 × 2550 | 9 |
GL165/0.3/35 | 55-210 | 00.3-1.2 | 35 | 360 | 37~75 | ≤6.0 | 3500 × 2300 × 2550 | 9 |
