모델 | 부피 흐름 Nm3/h | 입수 압력 MPa | 배기 압력 MPa | 혁명 rpm | 모터 전력 kW | 냉각 물 흐름 m3/h | 크기 (L×W×H) mm | 무게 톤 |
GL130/0/1.5 | 80-1400 | 0-1.2 | 1.5 | 400 | 18.5-37 | ≤3.2 | 2600×1630×1850 | 4 |
GL130/0.25/2.5 | 160~1300 | 0.25-2.0 | 2.5 | 400 | 22~37 | ≤3.2 | 2600×1630×1850 | 4 |
GL130/0.3/3 | 140~1200 | 00.3-25 | 3 | 400 | 30~37 | ≤3.2 | 2600×1630×1850 | 4 |
GL130/0/4 | 40~200 | 0-0.4 | 4 | 400 | 22~37 | ≤3.2 | 2600×1630×1850 | 4 |
GL130/0/6 | 30~160 | 0-0.45 | 6 | 400 | 22~37 | ≤3.2 | 2600×1630×1850 | 4 |
GL130/0.2/16 | 40~180 | 0.2-12 | 16 | 400 | 22~37 | ≤3.2 | 2600×1630×1850 | 4 |
GL130/0/20 | 40-45 | 0-0.012 | 20 | 400 | 22 | ≤1.8 | 2240×1490×1850 | 4 |
GL130/0.01/20 | 28-56 | 00.01-0.1 | 20 | 400 | 18.5-22 | ≤1.8 | 2240×1490×1850 | 4 |
GL130/0/20 | 20~80 | 0-0.2 | 20 | 400 | 15 ~ 37 | ≤3.2 | 2600×1630×1850 | 4 |
GL130/0.1/25 | 55-100 | 00.1-0.2 | 25 | 400 | 22~37 | ≤3.2 | 2600×1630×1850 | 4 |
GL130/2/80 | 40~150 | 20.0-6.0 | 80 | 400 | 22~37 | ≤3.2 | 2600×1630×1850 | 4 |
