모델 | 유량 Nm³/h | 입구 압력 MPa | 배기 압력 MPa | 회전수 rpm | 모터 출력 kW | 냉각수 유량 m³/h | 치수 (L×W×H)mm | 무게 톤 |
GZ130/0/1.5 | 40-700 | 0-1.2 | 1.5 | 400 | 15-18.5 | ≤1.4 | 1800×1290×1900 | 2.6 |
GZ130/0/2 | 28-600 | 0-1.5 | 1.0-2.0 | 400 | 15-18.5 | ≤1.4 | 1800×1290×1900 | 2.6 |
GZ130/0.3/3 | 70-600 | 0.3-2.5 | 3 | 400 | 15-18.5 | ≤1.4 | 1800×1290×1900 | 2.6 |
GZ130/0.4/4 | 70-700 | 0.4-3.5 | 4 | 400 | 15-18.5 | ≤1.4 | 1800×1290×1900 | 2.6 |
GZ130/0.5/5 | 70-700 | 0.5-4.5 | 5 | 400 | 15-18.5 | ≤1.4 | 1800×1290×1900 | 2.6 |
GZ130/0.7/7 | 60-650 | 0.7-6.5 | 7 | 400 | 15-18.5 | ≤1.4 | 1800×1290×1900 | 2.6 |
GZ130/1.2/16 | 46-650 | 1.2-14.0 | 16 | 400 | 15-18.5 | ≤1.4 | 1800×1290×1900 | 2.6 |
GZ130/1.3/20 | 40-650 | 1.3-16.0 | 20 | 400 | 15-18.5 | ≤1.4 | 1800×1290×1900 | 2.6 |
GZ130/5/45 | 50-325 | 5.0-20.0 | 45 | 430 | <22 | ≤1.8 | 2100×1500×1900 | 3 |
GZ130/8/80 | 36-600 | 8.0-70.0 | 80 | 400 | 22 | ≤1.8 | 2100×1500×1900 | 3.5 |
